How to inspect the triangular belt after installation?

Inspection method after installation of triangular belt

1. Before proper installation, install the triangular belt and use the same method to install a set of triangular belts.

2. The correct inspection method is to apply a vertical pressure of about 2 kilograms by hand in the middle of each tape, with a sinking amount of 20-30 millimeters. If it is not appropriate, it should be adjusted in a timely manner.

3. The selected model should be compatible with the selected triangular belt, otherwise the triangular belt may have abnormal situations in the pulley groove. When switching to a triangular belt, bring the old belt to the agricultural machinery department to purchase to prevent the wrong model.

4. When installing belt pulleys in a series of grooves, the centers of the two upper pulleys need to be aligned, otherwise it will cause the triangular belt to work unilaterally, cause severe wear, and reduce the service life of the triangular belt.

5. Daily maintenance machine operators and users should master the correct operating essentials during normal driving, follow the technical requirements of the user manual, and try to avoid sudden starting and braking as much as possible; Frequent overload operations should also be prevented; When the machine is out of use for a long time, the triangular belt should be removed and stored separately.

6. Strictly prevent contamination. During use, it is necessary to strictly prevent oil and mud stains on the triangular belt, avoid contact with corrosive substances such as acids and alkalis, and prevent early damage caused by slipping and corrosion of the triangular belt.

7. The tightness of the triangle belt needs to be regularly checked and adjusted to meet the requirements. If the triangular belt is too loose, it is not only easy to slip, but also increases the wear of the triangular belt, and even cannot transmit power; If it is too tight, the V-belt will not only be stretched and deformed, but also be easily damaged. At the same time, the engine main bearing and clutch bearing will be forced too much, which will accelerate the wear of the V-belt.

8. When two or more triangular belts need to be replaced, a specified model of triangular belt should be selected and the tightness of each group of triangular belts should be consistent.

Triangle belt is a component used in mechanical equipment to transmit mechanical power, and is one of the components in almost all equipment. Various faults may occur during the use of triangular belts. Insufficient tension: If the tension is not enough, the friction force will also be insufficient, leading to slipping, increasing the wear of the V-belt and causing other parts to lose their ability to transmit loads. The unstable transmission makes the belt transmission ineffective. Excessive tension: The tension that the triangular belt bears is too high, causing severe deformation, which will reduce the service life of the triangular belt.

Debris left on the triangular belt: If there is oil and other dirt left on the triangular belt, it can enter the triangular belt because the dirt contains chemicals, which can damage its material structure and composition. Triangle pulley not aligned: If the triangle pulley is not aligned, it will cause the triangle belt to slip, twist, and internal heat and wear. Therefore, the triangle pulley needs to be aligned instead.

The triangular belt has a simple structure, stable transmission, low noise, and is suitable for occasions with large center distance between two axles. It has the function of buffering and vibration absorption. To ensure that the appearance of the triangular belt is neat and beautiful, it needs to be trimmed. Manual trimming is the original trimming method, which is time-consuming and labor-intensive. For products with strict requirements, slight carelessness during trimming may result in scrap, so it needs to be treated with caution. For products with complex configurations and high precision requirements, it is difficult to achieve complete and clean cleaning, and it is easy to damage the connection between the product body and the overflow edge; In order to achieve good speed increase and quality, mechanical trimming methods are needed.

Triangle belts are components used in various mechanical equipment to transmit the power generated by the prime mover. In order to make them more stable, triangular belts are usually manufactured using composite fiber materials. Compared to traditional rubber resin materials, composite fibers have many advantages. Here is a detailed introduction to the characteristics of the fiber materials composed of toothed belts, hoping to be helpful to you.

1. The modulus and bending stiffness are half of polyester, making it soft to the touch;

2. Dyeability, dyeing temperature lower than polyester.

3. Has good hydrophilicity, capillary effect, and water dispersibility;

4. Has outstanding resilience and shape retention;

5. The material comes from natural plants and is simply biodegradable. The degradation products are lactic acid, carbon dioxide, and water, making it a new generation of environmentally friendly and biodegradable polyester fiber;

6. Has the ability to be afraid of ultraviolet radiation, with low ultraviolet absorption rate;

7. Low refractive index, good color rendering of dyed products.
