The Correct Usage Method of The Harvester Belt

With the development of agricultural mechanization, harvesters have played an important role in agricultural operations. The transmission accessories of the harvester are the well-known triangular belt. Once the triangular belt has problems, it will directly affect the normal operation of the harvester. Next, we will talk about the correct usage method of the harvester belt.

1. The V-belt used in the harvester is a belt that matches the pulley to achieve transmission. If friction occurs between the bottom surface of the belt and the bottom surface of the pulley groove, it indicates that the two do not match or wear has occurred. At this time, it is necessary to replace one of the two according to the situation.

2. When installing the V-belt, remember not to use brute force to pry it off or on, as this will not only damage the pulley but also the V-belt.

3. Properly adjust the tension of the V-belt. If the V-belt is too loose, it will slip and cannot effectively transmit power. It should be checked and adjusted frequently to avoid excessive wear, elongation, and shortened service life of the belt. At the same time, attention should be paid to preventing the belt body from occupying oil and slipping.

4. The new and old straps cannot be used together, otherwise it may affect the service life of the triangular strap.

5. Generally speaking, V-belts and V-belts are used together. If one of them is damaged and needs to be replaced, the remaining ones should be replaced together and cannot be mixed with new and old ones.
