V-belt Use and Storage Matters and Function Summary

Before installing the v belt, if the spacing between the two axes is adjustable, the spacing should be shortened first. After installing the tape, adjust the spacing according to the needs; If the spacing between the two shafts cannot be adjusted, a v belt can be inserted into the wheel groove first, and then the other pulley can be changed to install the v belt. Use the same method to install a set of v belts.

Do not use anything to pry or pull on the triangular tape during installation to prevent the triangular tape from extending or becoming too loose or tight. When installing belt pulleys in a series of grooves, the middle of the two upper pulleys should be aligned, otherwise it will form a single sided operation of triangular tape, which will cause severe wear and reduce the service life of the triangular tape. The tightness of triangular tape should be frequently checked and adjusted to meet the requirements.

Excessive looseness of the v belt not only leads to simple slipping, but also increases the wear of the v belt, and even cannot transmit power; If it is too tight, it will not only stretch, deform and simply damage it, but also form the clutch bearing of the main bearing of the starter, which will accelerate the wear of the V-belt due to excessive force.

V belt is a type of rubber product that can be used on conveying equipment, which can support and transport the required materials. It can reduce the consumption of manpower and material resources and improve the production rate.

Here are the precautions for using and storing triangular belts:

1. The v belt should be kept clean during transportation and storage to avoid direct sunlight and rain and snow. Contact with substances that affect the quality of rubber such as acids, alkalis, and oil solvents, and be located 1 meter away from the heating device.

2. The operating speed of the v belt should not exceed 5.0 meters per second when transporting materials with large block size and high wear resistance, and when using a fixed plow type unloading device, low speed should be used as much as possible. Exceeding the specified speed will affect the service life of the tape.

3. During storage, the v belt must be placed in rolls and cannot be folded. During storage, it should be flipped once a season.

4. During storage, the temperature in the warehouse should be maintained between -15 ℃ -+40 ℃, and the relative humidity should be maintained between 50-80%.

After the installation of the v belt, it is necessary to conduct an installation inspection. During the inspection, a straight pressure of about 2 kilograms should be applied by hand in the middle of each tape, and the sinking amount should be (20-30) millimeters. If it is not in order, it should be adjusted in a timely manner. When replacing double or more triangular tapes with new and old ones, regular types of triangular tapes should be selected, and the tightness of each group of triangular tapes should be common. It is necessary to avoid mixing new and old tapes or reducing the number of tapes. If the force on the new and old triangular tapes is uneven, it will make the old triangular tapes ineffective, affect power transmission, and shorten the service time of the triangular tapes.

Triangle belt is one of the transmission parts in mechanical operation, and it can be said that its role in mechanical operation is quite significant. Some people also say that it is a part of mechanical operation. We all know that the cross-section of relatively standardized triangular belts is trapezoidal, with no joints throughout the entire circle. They are divided into 7 types: O type, A type, B type, C type, D type, E type, and F type. The cross-sectional area gradually increases from O type to F type. These are some small knowledge when using it.

The summary of its functions is as follows:

1. When installing the pulley, it is important to ensure that the centers of the two upper pulleys are aligned, otherwise it may cause the triangular belt to work on one side, causing severe wear and tear, and not reducing the service life of the triangular belt.

2. The tightness of the v belt needs to be regularly checked and adjusted to meet the requirements. If the triangular belt is too loose, it is not only easy to slip, but also increases the wear of the v belt, and even cannot transmit power; If it is too tight, it will not only elongate and deform the triangular belt, which is easy to damage, but also cause starting.

3. When two or more new and old triangular belts need to be replaced, a specified model of triangular belt should be selected, and the tightness of each group of triangular belts should be consistent. It is not allowed to mix new and old triangular belts or reduce the number of pieces. Otherwise, the force on the new and old triangular belts will be uneven, and even the old triangular belts will not work, to avoid affecting the transmission of power and the use of machinery.

4. Strictly prevent contamination. During use, it is necessary to strictly prevent oil and mud stains on the triangular belt, avoid contact with corrosive substances such as acids and alkalis, and prevent early damage caused by slipping and corrosion of the triangular belt.

They will tell us some knowledge about its installation. We need to regularly check whether the installation is too tight. After adjusting the tension, it still cannot meet the specified requirements and needs to be replaced with a new one. When replacing, all belts on the same pulley should be replaced at the same time. Otherwise, due to the difference in length between the old and new, the load distribution is uneven, resulting in vibration, unstable transmission, and a decrease in the working rate of the transmission.
